Specs: RZR PRO XP 4 ULTIMATE SUPER GRAPHITE

RZR PRO XP 4 ULTIMATE SUPER GRAPHITE SPECIFICATIONS

Find specifications below for the 2024 Polaris RZR Pro XP 4 Ultimate Super Graphite Side by Side. Specs include ground clearance, wheelbase, box capacity, cargo system, engine braking system, instrumentation, lighting, travel, horsepower, engine, seat type and suspension.

ENGINE & DRIVETRAIN
Cooling	Liquid
Cylinders Displacement	925cc
Drive System Type	Isolated Xtreme Performance True On- Demand AWD/2WD
Engine Braking System (EBS)	Not Equipped
Engine Type	4-Stroke DOHC Twin Cylinder Turbocharged
Fuel System/Battery	Electronic Fuel Injection
Horsepower	181 HP
Transmission/Final Drive	Automatic PVT P/R/N/L/H
DIMENSIONS
Bed Box Dimensions (L x W x H)	26 x 17.7 x 11.5 in (66 x 45 x 29.2 cm)
Box Capacity	300 lb (136 kg)
Estimated Dry Weight	2,066 lb (937 kg)
Fuel Capacity	13 gal (49.2 L)
Ground Clearance	14.5 in (36.8 cm)
Hitch Towing Rating	N/A
Overall Vehicle Size (L x W x H)	155 x 64 x 73.6 in (393.7 x 162.6 x 186.9 cm)
Payload Capacity	900 lb (408.2 kg)
Wheelbase	125 in (317.5 cm)
BRAKES
Front/Rear Brakes	4-Wheel Hydraulic Disc with Dual-Bore XL Front and Dual-Bore Rear Calipers
Parking Brake	Park In-Transmission
ADDITIONAL SPECIFICATIONS
Cargo System	Lock & Ride® Fold Flat Rear Storage, convertible rear seat storage with integrated tie down points, 27.7 x 52.8 x 19.5 in (70.4 x 134.1 x 49.53 cm)
Doors	Front & Rear Full Doors
Electronic Power Steering	High Assist Electronic Power Steering with Quick Turn Rack; Race Inspired Steering Wheel with Tilt and Telescoping Adjustment; DYNAMIX and RIDE COMMAND Push Button Controls
Hitch Type	Not Equipped
Instrumentation	7” Glove-Touch Display: DYNAMIX 2.0 Visualizer, Built-In GPS, *Group Ride (Cell- Based or GPS Based), Topographic Mapping, Bluetooth & USB Smartphone Connectivity, AM/FM & Weather Radio, In- Vehicle Communications Capable With Optional Sena Headsets, Rockford Fosgate® Premium Audio (Including 2 Front Speakers and an External 400W 4- Channel Amplifier) Dual-Sweep Analog Dials with 4 in LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals. Digital Instrumentation: Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder Light, Gear Indicator, DC Outlet
Lighting	Signature White LED, Low/High & Red LED Tail/Brake Lights; Front & Rear LED Accent Lights; Interior Accent Lighting
Other Standard Features	RIDE COMMAND, High Output 900W Charging System with Sealed Electrical, Polaris Pulse System, USB Charging, Front Bumper, In-Dash Charge Port, Color Matched Seats, Polaris P.A.S.S., Rockford Fosgate® Stage 3 Audio
Seat Type	Front Bolstered Bucket Seats with 4-way adjustability (including 6 in front to back toolless seat sliders with tilt adjustability) and Retractable Click-6 Harnesses, Rear Stadium style seating with Click-6 harnesses
TIRES / WHEELS
Front Tires	30 x 10-14 Maxxis Carnivore; 8-Ply Rated; Wheel Size 14x6
Rear Tires	30 x 10-14 Maxxis Carnivore; 8-Ply Rated; Wheel Size 14x7
Wheels	Cast Aluminum
SUSPENSION
Electronic Suspension Control System	DYNAMIX 2.0 Active Suspension System
Front Shocks	FOX® 2.5 Podium Shocks with Live Valve (Electronically Controlled Damping)
Front Suspension	High-Clearance Dual A-Arm with Stabilizer Bar and 20 in (50.8 cm) *Usable Travel, 17 in (43.2 cm) Wheel Travel
Rear Shocks	FOX® 2.5 Podium Shocks with Live Valve (Electronically Controlled Damping)
Rear Suspension	Trailing Arm & Standard-Clearance Radius Rods with Stabilizer Bar and 22 in (55.9 cm) *Usable Travel, 20 in (50.8 cm) Wheel Travel

*Usable Travel is measured, with the vehicle in full droop, from the bottom of the tire to the bottom of the skid plate.
*Group Ride only available on North America models.
